DS1072CA  |  70 MHz Digital Oscilloscope

 Selection Guide View Larger Image
Array ( [status] => Array ( [0] => 1 [1] => DS1072CA ) )
DS1072CA
Price: $745
Ships in 4-6 weeks

The DS1000CA Series Digital Oscilloscopes set a new standard for technology and capability. With features including 2GSa/s sample rate, FFTs, record and replay, roll mode, alternate trigger mode, adjustable trigger sensitivity, and PictBridge printing the DS1000CA is the new bench standard.
  • 2 Analog channels plus external trigger
  • 2GSa/s real-time sample rate and 50GSa/s equivalent-time sample rate.
  • Up to 2000wfms/s waveform update rate
  • 5.7” TFT QVGA (320X240) with 64K color LCD backlit display
  • Trigger modes: edge, pulse width, slope, video, pattern, continuous time, and alternate
Model
Bandwidth
70 MHz
Analog Channels
2
Vertical Sensitivity
1 mV/div ~ 10V/div
Real-time Sample Rate
2 GSa/s（each channel），1GSa/s（dual channels）
Equivalent Sample Rate
10 GSa/s
Standard Interface
USB Host & Device, RS-232, P/F Out
Vertical Resolution
8 bits
Math
＋, －, ×, FFT
Max Input Voltage
All inputs 1MΩ‖15pF 300 V RMS CATⅠ
Cursor Measurements
Manual, Track and Auto Measure modes
DS1000CA Specs

Datasheets

DS1000CA Datasheet

Array ( [0] => Array ( [Id] => 501G00000001O3aIAE [LastModifiedById] => 005A0000000ECzEIAW [OwnerId] => 005A0000000ECzEIAW [SystemModstamp] => 2012-05-15 20:08:12 [Products_Related__c] => DS1CA Family [Category__c] => [NeedsUpdated__c] => True [MobileSite__c] => [MobileURL__c] => [CurrencyIsoCode] => USD [SolutionLink__c] => [CreatedById] => 005A0000000ECzEIAW [IsPublished] => False [IsPublishedInPublicKb] => False [TimesUsed] => 0 [Status] => Reviewed [IsDeleted] => False [SolutionName] => DS1000CA Quickguide [CreatedDate] => 2012-04-30 04:08:05 [LastModifiedDate] => 2012-05-15 20:08:12 [IsHtml] => False [SolutionNote] => [SolutionNumber] => 312 [Type__c] => User's Manual [News_Expiration_Date__c] => [VideoUrl__c] => [PublicUrl__c] => http://beyondmeasure.rigoltech.com/acton/attachment/1579/f-00aa/0/-/-/-/-/file.pdf [Optional_Accessory__c] => False [IsReviewed] => True [lastUpdate] => 2012-09-05 00:00:00 ) [1] => Array ( [Id] => 501G00000001O44IAE [LastModifiedById] => 005A0000000ECzEIAW [OwnerId] => 005A0000000ECzEIAW [SystemModstamp] => 2012-05-15 20:08:12 [Products_Related__c] => DS1CA Family [Category__c] => [NeedsUpdated__c] => True [MobileSite__c] => [MobileURL__c] => [CurrencyIsoCode] => USD [SolutionLink__c] => [CreatedById] => 005A0000000ECzEIAW [IsPublished] => False [IsPublishedInPublicKb] => False [TimesUsed] => 0 [Status] => Reviewed [IsDeleted] => False [SolutionName] => DS1000CA User's Guide [CreatedDate] => 2012-04-30 04:13:20 [LastModifiedDate] => 2012-05-15 20:08:12 [IsHtml] => False [SolutionNote] => [SolutionNumber] => 318 [Type__c] => User's Manual [News_Expiration_Date__c] => [VideoUrl__c] => [PublicUrl__c] => http://beyondmeasure.rigoltech.com/acton/attachment/1579/f-002f/0/-/-/-/-/file.pdf [Optional_Accessory__c] => False [IsReviewed] => True [lastUpdate] => 2012-09-05 00:00:00 ) [2] => Array ( [Id] => 501G00000001SPfIAM [LastModifiedById] => 005A0000000ECzEIAW [OwnerId] => 005A0000000w9PGIAY [SystemModstamp] => 2012-10-02 12:38:29 [Products_Related__c] => All Scopes [Category__c] => [NeedsUpdated__c] => True [MobileSite__c] => [MobileURL__c] => [CurrencyIsoCode] => USD [SolutionLink__c] => [CreatedById] => 005A0000000w9PGIAY [IsPublished] => True [IsPublishedInPublicKb] => True [TimesUsed] => 0 [Status] => Reviewed [IsDeleted] => False [SolutionName] => Probe Data Sheet [CreatedDate] => 2012-08-21 19:52:44 [LastModifiedDate] => 2012-10-02 12:38:29 [IsHtml] => False [SolutionNote] => Here is a document that contains Rigol Probe specifications. [SolutionNumber] => 00000420 [Type__c] => User's Manual [News_Expiration_Date__c] => 0000-00-00 [VideoUrl__c] => [PublicUrl__c] => http://beyondmeasure.rigoltech.com/acton/attachment/1579/f-0191/0/-/-/-/-/file.pdf [Optional_Accessory__c] => False [IsReviewed] => True [lastUpdate] => 2012-09-05 00:00:00 ) [3] => Array ( [Id] => 501G00000001OMwIAM [LastModifiedById] => 005A0000000ECzEIAW [OwnerId] => 005A0000000w9PGIAY [SystemModstamp] => 2012-05-15 20:08:12 [Products_Related__c] => All Scopes [Category__c] => [NeedsUpdated__c] => True [MobileSite__c] => [MobileURL__c] => [CurrencyIsoCode] => USD [SolutionLink__c] => [CreatedById] => 005A0000000w9PGIAY [IsPublished] => True [IsPublishedInPublicKb] => False [TimesUsed] => 0 [Status] => Reviewed [IsDeleted] => False [SolutionName] => Oscilloscope Declassification Guide [CreatedDate] => 2012-05-09 18:12:55 [LastModifiedDate] => 2012-05-15 20:08:12 [IsHtml] => False [SolutionNote] => This document outlines the types of memory, locations, and sanitization process for the current Oscilloscopes. [SolutionNumber] => 370 [Type__c] => User's Manual [News_Expiration_Date__c] => [VideoUrl__c] => [PublicUrl__c] => http://beyondmeasure.rigoltech.com/acton/attachment/1579/f-0162/0/-/-/-/-/file.pdf [Optional_Accessory__c] => False [IsReviewed] => True [lastUpdate] => 2012-09-05 00:00:00 ) ) Array ( [0] => Array ( [Id] => 501G00000001O3aIAE [LastModifiedById] => 005A0000000ECzEIAW [OwnerId] => 005A0000000ECzEIAW [SystemModstamp] => 2012-05-15 20:08:12 [Products_Related__c] => DS1CA Family [Category__c] => [NeedsUpdated__c] => True [MobileSite__c] => [MobileURL__c] => [CurrencyIsoCode] => USD [SolutionLink__c] => [CreatedById] => 005A0000000ECzEIAW [IsPublished] => False [IsPublishedInPublicKb] => False [TimesUsed] => 0 [Status] => Reviewed [IsDeleted] => False [SolutionName] => DS1000CA Quickguide [CreatedDate] => 2012-04-30 04:08:05 [LastModifiedDate] => 2012-05-15 20:08:12 [IsHtml] => False [SolutionNote] => [SolutionNumber] => 312 [Type__c] => User's Manual [News_Expiration_Date__c] => [VideoUrl__c] => [PublicUrl__c] => http://beyondmeasure.rigoltech.com/acton/attachment/1579/f-00aa/0/-/-/-/-/file.pdf [Optional_Accessory__c] => False [IsReviewed] => True [lastUpdate] => 2012-09-05 00:00:00 ) [1] => Array ( [Id] => 501G00000001O44IAE [LastModifiedById] => 005A0000000ECzEIAW [OwnerId] => 005A0000000ECzEIAW [SystemModstamp] => 2012-05-15 20:08:12 [Products_Related__c] => DS1CA Family [Category__c] => [NeedsUpdated__c] => True [MobileSite__c] => [MobileURL__c] => [CurrencyIsoCode] => USD [SolutionLink__c] => [CreatedById] => 005A0000000ECzEIAW [IsPublished] => False [IsPublishedInPublicKb] => False [TimesUsed] => 0 [Status] => Reviewed [IsDeleted] => False [SolutionName] => DS1000CA User's Guide [CreatedDate] => 2012-04-30 04:13:20 [LastModifiedDate] => 2012-05-15 20:08:12 [IsHtml] => False [SolutionNote] => [SolutionNumber] => 318 [Type__c] => User's Manual [News_Expiration_Date__c] => [VideoUrl__c] => [PublicUrl__c] => http://beyondmeasure.rigoltech.com/acton/attachment/1579/f-002f/0/-/-/-/-/file.pdf [Optional_Accessory__c] => False [IsReviewed] => True [lastUpdate] => 2012-09-05 00:00:00 ) [2] => Array ( [Id] => 501G00000001SPfIAM [LastModifiedById] => 005A0000000ECzEIAW [OwnerId] => 005A0000000w9PGIAY [SystemModstamp] => 2012-10-02 12:38:29 [Products_Related__c] => All Scopes [Category__c] => [NeedsUpdated__c] => True [MobileSite__c] => [MobileURL__c] => [CurrencyIsoCode] => USD [SolutionLink__c] => [CreatedById] => 005A0000000w9PGIAY [IsPublished] => True [IsPublishedInPublicKb] => True [TimesUsed] => 0 [Status] => Reviewed [IsDeleted] => False [SolutionName] => Probe Data Sheet [CreatedDate] => 2012-08-21 19:52:44 [LastModifiedDate] => 2012-10-02 12:38:29 [IsHtml] => False [SolutionNote] => Here is a document that contains Rigol Probe specifications. [SolutionNumber] => 00000420 [Type__c] => User's Manual [News_Expiration_Date__c] => 0000-00-00 [VideoUrl__c] => [PublicUrl__c] => http://beyondmeasure.rigoltech.com/acton/attachment/1579/f-0191/0/-/-/-/-/file.pdf [Optional_Accessory__c] => False [IsReviewed] => True [lastUpdate] => 2012-09-05 00:00:00 ) [3] => Array ( [Id] => 501G00000001OMwIAM [LastModifiedById] => 005A0000000ECzEIAW [OwnerId] => 005A0000000w9PGIAY [SystemModstamp] => 2012-05-15 20:08:12 [Products_Related__c] => All Scopes [Category__c] => [NeedsUpdated__c] => True [MobileSite__c] => [MobileURL__c] => [CurrencyIsoCode] => USD [SolutionLink__c] => [CreatedById] => 005A0000000w9PGIAY [IsPublished] => True [IsPublishedInPublicKb] => False [TimesUsed] => 0 [Status] => Reviewed [IsDeleted] => False [SolutionName] => Oscilloscope Declassification Guide [CreatedDate] => 2012-05-09 18:12:55 [LastModifiedDate] => 2012-05-15 20:08:12 [IsHtml] => False [SolutionNote] => This document outlines the types of memory, locations, and sanitization process for the current Oscilloscopes. [SolutionNumber] => 370 [Type__c] => User's Manual [News_Expiration_Date__c] => [VideoUrl__c] => [PublicUrl__c] => http://beyondmeasure.rigoltech.com/acton/attachment/1579/f-0162/0/-/-/-/-/file.pdf [Optional_Accessory__c] => False [IsReviewed] => True [lastUpdate] => 2012-09-05 00:00:00 ) )

User's Manual(s)

DS1000CA Quickguide

DS1000CA User's Guide

Probe Data Sheet

Oscilloscope Declassification Guide

Programming Manual(s)

DS1000CA Programming Guide

Specifications

DS1000CA Specs

Service Manuals

3 Year Product Warranty Agreement

Catalogs

Full Line Catalog

Product Selection Guide

To get started using your instruments over the bus download UltraSigma instrument communication software or for older instruments or customized installations review the How to Guide:
Using VISA and drivers to communicate with instruments

For help writing your own programs for our instruments review the programming manual or contact us directly.

Software Applications

Simple Excel VBA Control program DS1000CA DS1000B Oscilloscopes

Ultrascope for DS1000CA

UltraScope User's Video

UltraScope Installation Video

UltraScope Windows 7 installation instructions

How do I install Ultra Signal Studio, Ultra Spectrum, or Ultra Power?

UltraSigma

C#.NET basic instrument communication example

User's Guide for UltraSigma Software

How do I install UltraSigma?

Standard Accessories (included)

  • Probes - qty. 2
    Probes - qty. 2



  • Packing Kit
    Packing Kit



  • Product CD
    Product CD



  • Calibration Certificate
    Calibration Certificate



  • Power Cord
    Power Cord



  • USB Cable
    USB Cable



Optional Accessories

  • Compare Instruments

    Price vs. Bandwidth

  • FAQs
    DS1000CA series Calibration Certificate
    Here is a sample of the Calibration Certificate for the DS1000CA family of oscilloscopes.

    How To Acquire Average waveforms from DS1000 Scopes
    DS1000 Series B and CA have firmware to write averaged waveforms to a USB stick. Averaged waveforms can be ported to computer with ULTRASCOPE


    How do I find the serial number and firmware revision of my DS1000 series of oscilloscope?
    Press Utility > Down arrow (Page 1/2) > Down arrow (Page 2/2) > Press Sys Info.


    How to open .WFM ( WFM Waveform files) under UltraScope?
    Please see the attached PDF instruction for a more detailed steps and screen-shots: 1: Under UltraScope click the icon of Add new memory waveform. 2: Click the File button in the File, and choose the .wfm file you want to open 3: Now the waveform


    Can I install UltraScope for Guests and Users without Administrative Privileges on Windows 7?
    By Default, Ultrascope will only be installed on the administrative user accounts. To use Ultrascope on Guest and other user accounts without administrative privileges, please follow the attached directions. Note: These instructions were developed on Win 7 and may not work


    How to use Ultrascope with Serial (RS-232) connections
    This document explains how to use a Serial connection with Ultrascope to remotely control and collect data from DS1k series of scopes.


    What are RCD files?
    Files that have the RCD extension are binary files used in Rigol DS1000 Series scopes to store waveform recordings. This file can be used to view recordings on a DS1000 Series scope or using UltraScope software.

    What is the capacitance of the RP6150 and RP6150A passive probe?
    1.6pF.


    Square wave displayed as sine wave on an oscilloscope.
    A scope user attempting to view a square wave on an oscilloscope might view a sine wave of the same frequency in place of a square wave. This is not a necessarily a sign of a defect with the scope or the generator, however an effect of the constituent hig


    Are your products UL or CSA listed?
    At this time, many of our products are C TUV USA listed. Per the TUV website, http://www.tuvasi.com/en/tests-and-analysis/information-about-nrtl-tests.htmlThe C TUV US mark is recognized as the equivalent and direct replacement to the UL and CSA m


    When I plug in my instrument via USB, I get a Windows Page Fault error ( Blue Screen of Death / BSoD ).
    There is a known issue with the IVI VISA Shared components version.See attached document for more details.


    What data set size is used to calculate the FFT on the DS series of scopes?
    The FFT is calculated using the displayed data set.DS1000E/D/B/CA series scopes = 600 Data pointsDS4000 series = 700 pointsDS6000 series = 700 points


    Software Compatibility
    The attached PDF file describes Windows 7 Compatibility Issues.


    Help File Error: Navigation to web page cancelled.
    Some instrument manuals are compiled HTML files with extensions ending in .CHM. On occasion, they have shown Navigation to web page cancelled. Here are some steps to help solve that error.


    Where do I find instrument drivers for LabVIEW?
    http://www.ni.com/downloads/idnet/


    Rigol Scopes VISA Driver Installation / Rigols UltraScope software not detect Rigol scope attached to PC via USB OR User receives Run Time Error '48': File not found VISA32.DLL error message when UltraScope is launched.
    The user either has not installed the latest available National Instruments VISA Runtime engine or the version of National Instruments VISA Runtime Engine included on the CD that the user installed is outdated.In both cases, the recommended solution


    VISA Runtime for Apple OS X
    To use a VISA compatible Rigol instrument under Apple OS X, the user must install National Instruments VISA run-time engine for OS XAs of this writing the latest OS X VISA run-time engine from National Instruments is NI-VISA 5.0NI-VISA 5.0 can be


    Can you set up any RIGOL scopes to stop triggering after a specific averaging number?
    Not at this time. The average acquisition mode for the DS1000E/D, DS1000CA, DS1000B, DS4000, and DS6000 scopes are identical in function. They collect a boxcar average of the last acquisitions on a rolling basis.


    How do I configure a DS1000B Series Oscilloscope to return maximum data lengths?
    This note covers how to configure the DS1000B series of oscilloscope to return the maximum data length.This can be useful for storing to a USB memory stick.


    RP2200 Users Guide


    RP1300H Users Guide


    RP3300 Users Guide


    RP5600 Users Guide


    RP6150 Users Guide


    RP1050H Users Guide


    Standard probes for all scopes
    Here is a listing of the standard probes that ship with each scope.


    Why does my data not appear to have 8 bits of resolution?
    The displayed data is a subset of the actual total measurement range. This is mainly due to a smaller number of vertical pixels than bits available. See attached for more details.


    Bits vs. dBs
    Here are instructions on converting bits of resolution to dBs.


    Benefits of deep memory
    Modern oscilloscopes feature many powerful tools to help you get your job done. Here are some of the benefits of deep memory.


    My Instrument IVI Driver does not appear in the LabVIEW tools palette.
    You may need to manually find and convert the IVI driver. See attachment for more details.


    The instrument not recognized over the USB bus
    In some cases, an instrument may not be recognized over the USB bus. Here are some troubleshooting hints to help.


  • Application Notes
    Utilizing deep memory with Rigol DS1000 Oscilloscope.
    Some Digital scopes offer the capability of capturing waveforms in Long Memory mode. Utilizing the long memory, Rigol scopes can capture complex signals in great detail over extended time periods. This allows an observer to examine high frequency effects


    Running the DSA800 from a Battery
    Includes performance data for DSA800 while running on battery.
