DG5102 Arbitrary Waveform Generator

View Larger Image
  • 100 MHz bandwidth
  • 1 GSa/Sec waveform output
  • 14 bit vertical resolution
  • 128 Million Points of Arbitrary Waveform Memory
  • Built in standard modulations including IQ modulation for digital baseband generation including QPSK and QAM formats
  • Standard Interfaces including LXI-C (Ethernet), USB device and host, and GPIB
  • Options including output amplifier (PA-1011), digital generator (DG-POD-A), and frequency hopping capability
Price: $4,200
In Stock

DG5102 is a multipurpose generator combining different capabilities including Function Generation, Arbitrary Waveform Generation, IQ Baseband Source/IQ IF Source, Frequency Hopping Source (optional) and Pattern Generation (optional). With single and true, independent, dual-channel models that provide adjustable phases between the two channels. The DG5102 adopts Direct Digital Synthesizer (DDS) technology, which providing stable, precise, low distortion signals. The user-friendly interface design and panel layout improves efficiency or utilize an interface for complete programmability.
Channels
2
Frequency
100 MHz
Sample Rate
1 GSa/s
Waveform Length
Up to 128 Million points
Resolution
1 μHz
Amplitude range
5 mVpp - 10 Vpp（50 Ω），10 mV - 20 Vpp（into open circuit）
Vertical Resolution
14 bits
Standard Interface
USB Host（2），USB Device， GPIB， LXI-C (Ethernet)
Options
Hop Frequency Module, Logic Signal Output Module, Power Amplifier
Weight
10 lbs.

For information on which interface or VISA layer to select and how to install review the How to Guide:
Using VISA and drivers to communicate with instruments

For help writing your own programs for our instruments review the programming manual or contact us directly.

Drivers

Software Applications

Standard Accessories

  • BNC to Alligator Clips
    BNC to Alligator Clips
  • CD Rom (includes manual and software)
    CD Rom (includes manual and software)
  • Calibration Form, Packing List, Warranty Card, and Quick Guide
    Calibration Form, Packing List, Warranty Card, and Quick Guide
  • USB Cable
    USB Cable
  • BNC Cable
    BNC Cable
  • Power Cord
    Power Cord

Optional Accessories

  • Digital Logic Output Module
    Digital Logic Output Module
  • 40dB Attenuator
    40dB Attenuator
  • PA-1011 10 W Power Amplifier
    PA-1011 10 W Power Amplifier

Purchase Products

Model: DG5102
Price: $4,200
In Stock

Current Offer 3 Year Warranty
